产品详情
|
材质&参数 MATERIAL
|
||
|
螺丝 Screw |
||
|
触点 Contact |
磷青铜 Phosphor Bronze | |
|
焊针 Pin header |
||
|
塑件 Plastic parts |
PA66, UL94V-0 | |
|
电气性能 ELECTRICAL |
UL | IEC |
|
额定电压 Rated voltage |
300V | 250V |
|
额定电流 Rated current |
10A | 7A |
|
接触电阻 Contact resistance |
20mΩ | |
|
绝缘电阻 Insulation resistance |
500MΩ/DC500V | |
|
耐电压 Withstanding voltage |
AC1500V/1min | |
|
使用线径 Wire range |
24-16AWG 0. 5-1.5mm2 | |
|
机械性能 MECHANICAL |
||
|
温度范围 Temp. range |
-40℃~+105℃ | |
|
瞬时温度 Max. soldering |
+250℃, 5sec | |
|
扭矩 Torque |
||
|
剥线长度 Strip length |
10mm | |
