产品详情
|
材质&参数 MATERIAL
|
||
|
螺丝 Screw |
M3.0,钢，镀锌 Steel, Zinc Plated |
|
|
方块 Clamp |
黄铜，镀镍 Brass, Ni plated |
|
|
焊针 Pin header |
黄铜，镀锡 Brass, Tin plated | |
|
塑件 Plastic parts |
PA66, UL94V-0 | |
|
电气性能 ELECTRICAL |
UL | IEC |
|
额定电压 Rated voltage |
300V | 750V |
|
额定电流 Rated current |
30A | 41A |
|
接触电阻 Contact resistance |
20mΩ | |
|
绝缘电阻 Insulation resistance |
500MΩ/DC500V | |
|
耐电压 Withstanding voltage |
AC3000V/1min | |
|
使用线径 Wire range |
26-10AWG 6.0mm2 |
|
|
机械性能 MECHANICAL |
||
|
温度范围 Temp. range |
-40℃~+105℃ | |
|
瞬时温度 Max. soldering |
+250℃, 5sec | |
|
扭矩 Torque |
0.5N.m 4.4Lb.in |
|
|
剥线长度 Strip length |
6-7mm | |
