产品详情
材质&参数 MATERIAL | ||
螺丝 Screw | M3.0,钢，镀锌 Steel, Zinc Plated | |
方块 Clamp | 黄铜，镀镍 Brass, Ni plated | |
焊针 Pin header | 黄铜，镀锡 Brass, Tin plated | |
塑件 Plastic parts | PA66, UL94V-0 | |
电气性能 ELECTRICAL | UL | IEC |
额定电压 Rated voltage | 300V | 450V |
额定电流 Rated current | 20A | 20A |
接触电阻 Contact resistance | 20mΩ | |
绝缘电阻 Insulation resistance | 500MΩ/DC500V | |
耐电压 Withstanding voltage | AC2500V/1min | |
使用线径 Wire range | 24-12AWG 4.0mm2 | |
机械性能 MECHANICAL | ||
温度范围 Temp. range | -40℃~+105℃ | |
瞬时温度 Max. soldering | +250℃, 5sec | |
扭矩 Torque | 0.5N.m 4.4Lb.in | |
剥线长度 Strip length | 6-7mm | |
