产品详情
|
材质&参数 MATERIAL
|
||
|
螺丝 Screw |
M4.0,钢，镀锌 Steel, Ni Plated |
|
|
端子 Terminal |
黄铜, 1.0t 镀锡 Brass, Tin Plated |
|
|
塑件 Plastic parts |
PA66, UL94V-0 | |
|
电气性能 ELECTRICAL |
UL | IEC |
|
额定电压 Rated voltage |
600V | 630V |
|
额定电流 Rated current |
40A | 41A |
|
绝缘电阻 Insulation resistance |
500MΩ/DC500V | |
|
耐电压 Withstanding voltage |
AC2000V/1min | |
|
试用线径 Wire range |
18-10AWG 6.0mm2 |
|
|
机械性能 MECHANICAL |
||
|
温度范围 Temp. range |
-40℃~+105℃ | |
|
扭矩 Torque |
25kgf.cm |
|
